HP ZBook 15 G2 Technical White Paper

Technical white paper | HP ZBook 15 G2 Mobile Workstation
© Copyright 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Intel and Thunderbolt are trademarks of Intel Corporation in the U.S. and other countries. NVIDIA is a trademark and/or registered trademark of NVIDIA
Corporation in the U.S and other countries. Microsoft and Windows are U.S. registered trademarks of the Microsoft group of companies. AMD is a
trademark of Advanced Micro Devices, Inc.
4AA5-4883ENW, September 2014
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full
advantage of Windows functionality. See microsoft.com.
2. Thunderbolt™ 2 is available via an optional add-in card on Z1, Z230 SFF, Z230 Tower, Z440, Z640 and Z840 Workstations. It is standard on ZBook 15 and 17 Mobile Workstations.
Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To determine whether your device is Thunderbolt Certied for Windows, see
thunderbolttechnology.net/products.
3. DisplayPort connector support a DisplayPort display, a HDMI display with an DP-to-HDMI dongle, a VGA display with a DP-to-VGA dongle, or a DVI display with a DP-to-DVI dongle.
4. With AMD Graphics, up to any 5 combination of these displays may be active when at least two external DisplayPort displays are used.
5. Multiple displays may be connected to DP 1.2 Hub. DP 1.2 Hub is connected to a DisplayPort connector on the HP ZBook or Docking Station.
6. Dependent on PCIe slot used and the capabilities of the M.2 module.
Resources, contacts, or additional links
HP ZBook Mobile Workstations
hp.com/go/zbook
More information on Secure Boot
HP Consumer Support: Secure Boot (Windows 8)
More information on Custom Integration
Services
HP Personal Systems: Conguration Services
Learn more at
hp.com/go/whitepapers
pcmag.com/article2/0,2817,2362046,00.asp
itdonut.co.uk/blog/2013/02/what-screen-
resolution-and-why-does-it-matter-0
gizmodo.com/5649389/giz-explains-
brightness
computer.howstuworks.com/monitor6.htm
slideshare.net/atops-lcd/lcd-panel-
technology-explained
tnpanel.com/tn-vs-ips-va/
rtings.com/images/optimal-viewing-distance-
wisegeek.org/what-is-an-anti-glare-
computer-screen.htm
bestprintingonline.com/monitors.htm
computerworld.com/s/article/9231961/
How_it_works_The_technology_of_touch_
screens?pageNumber=1
Customer advantage
The HP Z Turbo Drive adds value to all targeted workstation customer segments. This oering
allows customers to realize performance gains due to improvements in storage performance.
Segments that have workows that use large data les and access the data sequentially will
see the most improvement in their performance.
These specic segments are:
• Product Dev/AEC
• Media & Entertainment
• Finance
• Oil and Gas
• G e o s p a t i a l
Summary
The transition from SATA to PCIe protocols for Solid State Devices enables customers to change
their use models and how they allocate their spending on workstation platforms. Continued
cost reductions in SSD devices will drive growth in usage. Additional growth is driven by the
performance improvement obtained with the move from SATA to PCIe protocol enabled by the
M.2 form factor. Utilizing the PCIe connection allows SSD devices to exceed 6 Gb/s performance.
The HP Z Turbo Drive oering on HP ZBook 15 G2 provides a huge performance gain over HDD,
enables large le/big data workows, and oers impressive price/performance for NAND
components. Integrating the HP Z Turbo Drive technology into HP platforms increases the
exibility of the storage subsystems and provides the user choice points around performance
and capacity that stand out in the industry.

HP ZBook 15 G2 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Country of origin	China
Bus type	DMI
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	PGA946
Processor threads	4
Processor codename	Haswell
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	37 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM87
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	750 GB
Compatible memory cards	SD, SDHC, SDXC
Panel type	SVA
Display surface	Matt
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K610M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	1 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
Number of discrete graphics cards supported	1
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	DTS Studio Sound HD
Front camera resolution	1280 x 720 pixels
WWAN	Not installed
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Processor code	SR1L4
Processor ARK ID	81012
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	75 Wh
Number of battery cells	8
AC adapter power	150 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Cable lock slot type	Kensington
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	257 mm
Width	381.5 mm
Height	30.5 mm
Weight	2780 g
