Item Component Spare part number
●
8-GB 820570-001
●
4-GB 820569-001
For use in models with Xeon Core processors
●
16-GB 835886-001
●
8-GB 835887-001
Heat sink assembly (includes replacement thermal material)
(16) For use only in models with UMA graphics memory 850150-001
(17) For use only in models with Nvidia Quadro graphics boards 850148-001
(17) For use only in models with the AMD FirePro graphics board 850149-001
(18) Solid-state drive (SSD)
1-TB, PCIe-3x4, NVMe 848238-001
512-GB, SATA-3, self-encrypting drive (SED), OPAL 2, TLC 848240-001
512-GB, Z Turbo drive, PCIe 848236-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 2 848237-001
256-GB, Z Turbo drive, PCIe 848235-001
(19) WWAN module
HP lt4120 LTE/EVDO/HSPA+ Gobi 4G Mobile Broadband Module 800870-001
HP hs3110 HSPA+ Mobile Broadband Module 822828-001
(20) WLAN module
Intel Dual Band Wireless-AC 8260 806721-001
Intel Dual Band Wireless-AC 8260 (non-vPro) 806722-001
Fan
(21) For use near the processor 848251-001
(22) For use near the graphics board 848252-001
(23) System board (includes battery connector bracket and replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 10 operating system
Equipped with an Intel Core i7-6820HQ processor 848221-xxx
Equipped with an Intel Core i7-6700HQ processor 848219-xxx
Equipped with an Intel Core i7-6440HQ processor 848217-xxx
(24) Bottom cover (includes SSD therrmal pad) 848227-001
18 Chapter 3 Illustrated parts catalog
