Remove the memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
2. Remove the memory module (2) by pulling the module away from the slot at an angle.
Reverse this procedure to install a memory module.
NOTE: Memory modules are notched to prevent incorrect installation.
34 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
