HP ZBook 15 Specification

At A Glance
Windows 8 versions, Windows 7 versions, SuSE Linux, or FreeDOS
All new, thinner and lighter form factor and industrial design for 2013. Durable HP Duracase with magnesium-reinforced chassis,
HP DuraFinish with brushed aluminum on top cover and smooth aluminum around top, right, and left sides chassis with hematite
/graphite color, HP DisplaySafe frame, latch-less design with precision aluminum-alloy hinges, backlight keyboard in full
aluminum deck, chemically strengthened glass touchpad, and updated system functions indicators
Designed to meet the military standard Mil-Std-810G for drop, vibration, shock, high temperature, low temperature,
temperature shock, dust, altitude, and humidity*
Workstation-caliber NVIDIA® Quadro® discrete graphics: NVIDIA Quadro K610M (1GB GDDR5), NVIDIA Quadro K1100M (2GB
GDDR5), NVIDIA Quadro K2100M (2GB GDDR5); NVIDIA Optimus technology enabled for improved battery life.
ISV certified to provide fast and reliable performance with workstation applications, including manipulation of 3D textures
Choice of 4th generation Intel® Core™ i7 and i5 processors
Intel Core i7 with vPro and Core i5 with vPro technology (optional)
Intel Smart Response Technology support for higher system performance with a hard drive
HP Performance Advisor for optimal configuration, compatibility and performance
Up to four SODIMMs on configurations with quad-core processor, for system memory up to 32 GB
Supports multi-display, including up to four without a docking station (both with and without hybrid graphics enabled), up to
four with HP Advanced Docking Station (sold separately)without hybrid graphics enabled and up to five with HP Advanced
Docking Station (sold separately) and hybrid graphics enabled
New Thunderbolt port** for high speed data/video/audio transfer support
Thunderbolt port can be connected to monitors supporting DisplayPort 1.2 to achieve HBR2 and MST functionality.
DTS Studio Sound HD audio optimized for high fidelity audio with immersive surround sound with deep, rich bass and crystal
clear dialog without distortion at high volume
Choice of battery solutions: 8-cell (83 WHr) or 8-cell (75 WHr) HP Long Life Battery, combined with optional external batteries
for extended life.
2 discrete buttons with LED indicator for convenient one touch access - Wireless On/Off, Volume Mute
Widescreen 15.6-inch diagonal anti-glare LED-backlit display:
HD (1920x1080) eDP with standard viewing angle, FHD (1920x1080) eDP with PSR (Panel Self Refresh) with ultrawide viewing
angle, or FHD ultrawide viewing angle with HP DreamColor Technology
Upgrade Bay for optical drive, optional second hard drive, or weight saver
Flexible wireless connectivity options:
Integrated Intel Centrino® 802.11 ac 2x2 + Bluetooth 4.0 LE**, Intel Centrino 802.11 a/b/g/n 2x2 + Bluetooth 4.0 LE, or
Intel Centrino a/b/g/n 2x2 wireless LAN modul
Optional integrated wireless 3G or 4G (LTE) mobile broadband module support
Choice of tool free capable, user-removable hard drive up to 1 TB with HP 3D DriveGuard protection,
or SATA 6 Gb/s 128/180/512*** GB Solid State Drive or 256 GB SED Solid State Drive
Security features including HP Client Security Manager, with central management
Low halogen****, ENERGY STAR qualified and EPEAT TBD registered in the U.S. EPEAT status varies by country- please see
epeat.net.
HP BIOS self-healing technology including HP Sure Start to prevent, detect, and remedy known and unknown BIOS attacks.
* MIL-STD-810G testing was not intended to demonstrate fitness for U.S. Department of Defense contracts or for military use. Test
results are not a guarantee of future performance under these test conditions.
** Thunderbolt is new technology. Install all the latest drivers for your Thunderbolt device before connecting the device to the
Thunderbolt port. Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To determine
whether your device is Thunderbolt Certified for Windows, see https://thunderbolttechnology.net/products.
*** Available in October, 2013.
**** External power supplies, power cords, cables and peripherals are not low halogen. Service parts obtained after purchase may not
be low halogen.
QuickSpecs
HP ZBook 15 Mobile Workstation
Overview
DA - 14722 North America — Version 7 — January 9, 2014 Page 3

HP ZBook 15 Specifications

General

Form factor	Clamshell
Product type	Mobile workstation
Product color	Black
Country of origin	China
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-4900MQ
System bus rate	- GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4900 Mobile Series
Processor socket	PGA946
Processor threads	8
Processor codename	Haswell
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	47 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM87
Memory slots	4x SO-DIMM
Internal memory	16 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K1100M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1300 MHz
Audio system	DTS Studio Sound HD
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Keyboard layout	-
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Processor code	SR15K
Processor ARK ID	75131
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	83 Wh
Battery life (max)	- h
AC adapter power	150 W
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	257 mm
Width	381.5 mm
Height	30.5 mm
Weight	2820 g
