PORTS/SLOTS
Ports
Left side:
(1) RJ-45 (Ethernet)
(1) USB 3.0
(1) USB 3.0 Charging Port
(1) Security lock slot
Right side:
(1) Power Connector
(2) Thunderbolt 3 (supporting DP 1.2, USB 3.1 Gen2, PCIe Gen 3 devices)
(1) HDMI
(1) USB 3.0
(1) Stereo microphone in / headphone-out combo jack
Thunderbolt  3
Thunderbolt3 ports supports DisplayPort 1.2, USB 3.1 Gen 2, and PCIe Gen 3 devices over the new USB-C port connector. The port
is compatible with existing DisplayPort displays, devices, and cables. Install all the latest drivers for your Thunderbolt device
before connecting the device to the Thunderbolt port. Thunderbolt cable and Thunderbolt device (sold separately) must be
compatible with Windows®. To determine whether your device is Thunderbolt Certified for Windows®, see
https://Thunderbolttechnology.net/products .
Digital Media Slots
(1) SD UHS-II Flash Media slot - Supports next generation SD (Secure Digital), backward compatible to SDHC, SDXC)
SERVICE AND SUPPORT
Limited 3-year or 1-year limited warranty options available, depending on country. Batteries have a default one year limited
warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. Optional
1
HP Care
Pack Services are extended service contracts which go beyond your standard limited warranties. To choose the right level of
service for your HP product, use the HP Care Pack Services Lookup Tool at http://www.hp.com/go/cpc .
Sold separately or as an optional feature.
1. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on
date of hardware purchase. Restrictions and limitations apply. HP services are governed by the applicable HP terms and
conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory
rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of
service or the HP Limited Warranty provided with your HP Product. Consult your local HP Customer Support Center for
details.
QuickSpecs
HP Zbook Studio G3 Mobile Workstation
Features
DA - 15377 Worldwide QuickSpecs — Version 3 — 12.18.2015 Page 15

HP Zbook Studio G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Black
Country of origin	China
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6800 Mobile Series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel CM236
Keyboard layout	QWERTY
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Processor code	SR2FU
Processor ARK ID	88970
Processor package size	42 x 28 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Connect Technology	-
Intel Smart Response Technology version	1.00
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® Quadro® M1000M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	64 Wh
Battery life (max)	- h
AC adapter power	150 W
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	255 mm
Width	375 mm
Height	18 mm
Weight	2000 g
