HP Zbook Studio G3 User Manual

OPERATING SYSTEM
Preinstalled
Windows® 10 Pro 64*
Windows® 10 Home 64*
Windows® 7 Professional 64 (available through downgrade rights from Windows® 10 Pro)**
Windows® 7 Professional 64*
FreeDOS 2.0
Supported
Windows® 10 Enterprise 64*
Windows® 7 Enterprise 64*
* Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased
hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically
updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See
http://www.microsoft.com .
**This system is preinstalled with Windows 7 Professional software and also comes with a license and media for Windows 10 Pro
software. You may only use one version of the Windows software at a time. Switching between versions will require you to
uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing
operating systems to avoid loss of your data.
PROCESSOR*
Intel® Xeon®E3-1545M v5 with Intel® Iris Pro Graphics P580 (
Available in 1H16
)
Intel® Xeon® E3-1505M v5 with Intel® HD graphics P530 (2.80 GHz, 2133 MHz, 8 MB L3 Cache, 4 Cores, 45W)
Up to 3.70 GHz with Intel® Turbo Boost Technology
Intel® Core i7-6820HQ with Intel® HD graphics 530 (2.70 GHz, 2133 MHz, 8 MB L3 Cache, 4 Cores, 45W)
Up to 3.60 GHz with Intel® Turbo Boost Technology
Intel® Core i7-6700HQ with Intel® HD graphics 530 (2.60 GHz, 2133 MHz, 6 MB L3 Cache, 4 Cores, 45W)
Up to 3.50 GHz with Intel® Turbo Boost Technology
* Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload
and your hardware and software configurations. Intel's numbering is not a measurement of higher performance.
Also note that the Intel® Turbo Boost is based on max GHz for a single core.
CHIPSET
Mobile Intel® CM236
QuickSpecs
HP Zbook Studio G3 Mobile Workstation
Features
DA - 15377 Worldwide QuickSpecs — Version 3 — 12.18.2015 Page 4

HP Zbook Studio G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Black
Country of origin	China
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6800 Mobile Series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel CM236
Keyboard layout	QWERTY
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Processor code	SR2FU
Processor ARK ID	88970
Processor package size	42 x 28 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Connect Technology	-
Intel Smart Response Technology version	1.00
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® Quadro® M1000M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	64 Wh
Battery life (max)	- h
AC adapter power	150 W
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	255 mm
Width	375 mm
Height	18 mm
Weight	2000 g
