HP Zbook Studio G3 User Manual

INTEL® CORE I7 WITH VPRO/XEON® WITH VPRO TECHNOLOGY CAPABLE
Intel® Core i7 with vPro and XEON® with vPro technology is a selectable feature that is available on units configured with
select processors, a qualified Intel® Centrino® WLAN module and a preinstalled Windows® operating system. It provides advances
in remote manageability, security, energy efficient performance, and wireless connectivity. Intel® Active Management Technology
(iAMT) offers built-in manageability and proactive security for networked mobile workstations, even when they are powered off*
or when the operating system is inoperable. It can help identify threats before they reach the network, isolate infected systems,
and update regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-VPN)
corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of Intel® Core i5 with vPro/Core i7 with vPro/Xeon® with vPro technology, such as Intel® Active
Management technology and Intel® Virtualization technology, requires additional third- party software in order to run. Availability
of future "virtual appliances" applications for Intel® Core i5 with vPro/Core i7 with vPro/XEON® with vPro technology is
dependent on third- party software providers. Compatibility with future "virtual appliances" is yet to be determined.
GRAPHICS
Intel Integrated
Intel® HD graphics 530*
Intel® HD graphics P530*
Intel® Iris Pro Graphics P580
(Available 1H16)
Discrete
NVIDIA® Quadro® M1000M with 2 GB dedicated GDDR5 video memory**
Microsoft DirectX 12 (Shader Model 5.0) and OpenGL 4.4 capable
* HD content required to view HD images.
**Optional or add-on feature.
NOTE: NVIDIA® Quadro® mobile professional graphics support up to four independent displays when using an HP ZBook Dock with
Thunderbolt 3 (sold separately) or DisplayPort 1.2 hubs with MST.
NVIDIA® Optimus Technology supported
NOTE 1: Color management on the UHD DreamColor panel is not supported while NVIDIA® Optimus Technology is activated.
DisplayPort 1.2 protocol features supported on Thunderbolt 3 ports:
Legacy displays (HDMI, DVI, VGA) may be attached to Thunderbolt port with the use of a
certified dongle.
DisplayPort monitors capable of supporting DisplayPort 1.2 may be directly attached to the
Thunderbolt port to achieve HBR2 with the use a dongle.
Thunderbolt 3 enabled monitors may be directly attached to the Thunderbolt port to achieve HBR2 and MST.
DisplayPort 1.2 MST feature ("daisy-chain" feature) is supported through Thunderbolt 3 port on
QuickSpecs
HP Zbook Studio G3 Mobile Workstation
Features
DA - 15377 Worldwide QuickSpecs — Version 3 — 12.18.2015 Page 5

HP Zbook Studio G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Black
Country of origin	China
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6800 Mobile Series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel CM236
Keyboard layout	QWERTY
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Processor code	SR2FU
Processor ARK ID	88970
Processor package size	42 x 28 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Connect Technology	-
Intel Smart Response Technology version	1.00
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® Quadro® M1000M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	64 Wh
Battery life (max)	- h
AC adapter power	150 W
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	255 mm
Width	375 mm
Height	18 mm
Weight	2000 g
