HP Zbook Studio G3 User Manual

At A Glance
Windows® 10 editions, Windows® 7 editions, or FreeDOS
Thin & light full performance industrial design, CNC machined top cover and keyboard deck. Top cover anodized in HP's new
"Space Silver" color with chemical etching. Bottom housing is constructed out of lightweight magnesium for durability. 2 piece
aluminum vented bottom cover for airflow. Backlight keyboard in full aluminum deck, chemically strengthened glass large
clickpad, and updated system functions indicators. Diamond cut process showcased around keyboard deck and clickpad.
HP Spill Resistant Keyboard with Durakeys
Designed to pass military standard Mil-Std-810G testing *
* MIL STD 810G testing is pending and is not intended to demonstrate fitness for U.S. Department of Defense contract
requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Damage
under the MIL STD test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.
Workstation-caliber NVIDIA® Quadro® discrete graphics: NVIDIA® Quadro M1000M (2GB GDDR5); NVIDIA® Optimus.
New Intel Integrated graphics options: Intel® HD Graphics 530 integrated on Core i7. Intel® HD Graphics P530 and Intel® Iris Pro
Graphics P580 integrated on Xeon® processors.
ISV certified to provide fast and reliable performance with workstation applications, including manipulation of 3D textures
(Note: HD 530 will not be ISV certified)
Choice of 6th generation Intel® Core i7 quad-Core or Xeon® processors.
Intel® Core i7 with vPro or Intel® Xeon® with vPro technology (optional)
HP Performance Advisor for optimal configuration, compatibility and performance
Up to two SODIMMs, for system memory up to 32GB. ECC memory with Intel® Xeon® processors.
Supports multi-display, including up to three displays without the use of a docking solution, with hybrid graphics enabled.
Supports up to five with HP ZBook Dock with Thunderbolt 3 (sold separately), with hybrid graphics enabled.
Two (2) Thunderbolt 3 ports (supporting DP 1.2, USB 3.1, PCIe Gen 3 devices) on the new USB-C
TM
connector, for high speed
data/video/audio transfer support.
Bang and Olufsen audio optimized for high fidelity audio with immersive surround sound with deep, rich bass and crystal clear
dialog without distortion at high volume
Long life battery solution: 4-cell (64 WHr)
2 discrete buttons with LED indicator for convenient one touch access - Wireless On/Off, Volume Mute
Widescreen 15.6-inch diagonal anti-glare LED-backlit display:
FHD (1920x1080) ultrawide viewing angle, UHD (3840x2160) ultrawide viewing angle, UHD (3840x2160) ultrawide viewing angle
with HP DreamColor Technology, or FHD Touch (1920x1080) ultrawide viewing angle
Wireless connectivity options:
Intel® Dual Band Wireless-AC 8260 802.11 ac/a/b/g/n (2x2) WiFi and Bluetooth® 4.0 combo (vPro) or,
Intel® Dual Band Wireless-AC 8260 802.11 ac/a/b/g/n (2x2) WiFi and Bluetooth® 4.0 combo (non-vPro)
Two dedicated drive slots. (2) M.2 slots. Both can be populated at a time.
Security features including HP Client Security Manager, managed via single console.
Low halogen HP BIOS technology, including HP Sure Start to identify and recover from unknown BIOS attacks.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP Zbook Studio G3 Mobile Workstation
Overview
DA - 15377 Worldwide QuickSpecs — Version 3 — 12.18.2015 Page 3

HP Zbook Studio G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Black
Country of origin	China
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6800 Mobile Series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel CM236
Keyboard layout	QWERTY
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Processor code	SR2FU
Processor ARK ID	88970
Processor package size	42 x 28 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Connect Technology	-
Intel Smart Response Technology version	1.00
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® Quadro® M1000M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	64 Wh
Battery life (max)	- h
AC adapter power	150 W
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	255 mm
Width	375 mm
Height	18 mm
Weight	2000 g
