AUDIO/MULTIMEDIA
Audio
Bang and Olufsen HD audio Integrated stereo speakers
Integrated microphone (dual-microphone array when equipped with optional webcam)
Button for volume mute; function keys for volume up and down
Combo microphone-in / stereo headphone-out jack
Webcam
Optional 720p HD* webcam
HD format (widescreen)
Supports videoconferencing and still image capture
High quality fixed focus lens
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and videoconferencing
Improved low light sensitivity
Improved dynamic range
*HD content required to view HD images.
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
Backlit keyboard with Function key control to toggle backlit brightness setting - off/full/half brightness
The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that funnels
fluid through a hole in the bottom of the notebook. This helps reduce the risk of damage to sensitive components underneath.
The 85-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as editing keys, both left
and right control and alt keys, function keys, and 18.7 x 18.4 mm key pitch (center-to-center spacing). U.S. and International key
layouts are available. Other features include hot keys for instant access to power conservation and brightness.
Pointing Devices
Large clickpad with On/Off button, two-way scroll, gestures, two integrated buttons within clickpad surface
Image sensor clickpad for enhanced performance and improved precision on scroll and gesture.
Buttons and Function Keys
Separate launch buttons provide easy access to the following features: wireless on/off, volume mute. Function keys provide
control of the following features:
standby mode, external display
, volume down, volume up, and display brightness.
SOFTWARE AND SECURITY
Preinstalled Software with Windows® Operating System
BIOS
HP BIOSphere
1
QuickSpecs
HP Zbook Studio G3 Mobile Workstation
Features
DA - 15377 Worldwide QuickSpecs — Version 3 — 12.18.2015
Page 9

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Zbook Studio G3 and is the answer not in the manual?

HP Zbook Studio G3 Specifications

General IconGeneral
Form factorClamshell
Product typeUltrabook
Product colorBlack
Country of originChina
Bus typeDMI3
SteppingR0
Tjunction100 °C
Processor cache8 MB
Processor cores4
System bus rate8 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-6800 Mobile Series
Processor socketBGA 1440
Processor threads8
Processor codenameSkylake
Processor frequency2.7 GHz
Processor cache typeSmart Cache
Configurable TDP-down35 W
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.6 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)45 W
Maximum number of PCI Express lanes16
Motherboard chipsetIntel CM236
Keyboard layoutQWERTY
Pointing deviceTouchpad
Spill-resistant keyboardYes
Recovery operating systemWindows 10 Pro
Operating system installedWindows 7 Professional
Processor codeSR2FU
Processor ARK ID88970
Processor package size42 x 28 mm
CPU configuration (max)1
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Intel Smart Connect Technology-
Intel Smart Response Technology version1.00
Memory slots2x SO-DIMM
Internal memory16 GB
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory32 GB
Memory layout (slots x size)2 x 8 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfacePCI Express
Storage mediaSSD
Total storage capacity512 GB
Compatible memory cardsSD
Display diagonal15.6 \
Native aspect ratio16:9
On-board graphics card ID0x191B
Discrete graphics card modelNVIDIA® Quadro® M1000M
On-board graphics card modelIntel® HD Graphics 530
Discrete graphics card memory2 GB
Discrete graphics memory typeGDDR5
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.7 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)1050 MHz
Battery capacity64 Wh
Battery life (max)- h
AC adapter power150 W
Number of built-in speakers2
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version4.2
Ethernet LAN data rates10, 100, 1000 Mbit/s
HDMI version1.4
Charging port typeDC-in jack
USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth255 mm
Width375 mm
Height18 mm
Weight2000 g
