HP zl2 User Manual

12
Specifications
Specifications
Physical
Power Supply: Weight
J9828A 2.44 kg (5.38 lbs)
J9829A 2.74 kg (6.03 lbs)
J9830A 4.19 kg (9.23 lbs)
J9828A, J9829A, J9830A
Width: 18.92 cm (7.45 in)
Depth: 15.87 cm (6.25 in)
Height: 12.95 cm (5.1 in)
Electrical
The HP zl2 Internal Power Supplies automatically adjust to any voltage
between 100-127 and 200-240 volts and either 50 or 60 Hz.
Electrical J9828A J9829A J9830A
Main Aux
AC voltage: 100 -127 volts; 200 - 240 volts 110 -127 volts; 200 - 240 volts 115-127; 200-
240 volts
115-127; 200-
240 volts
Maximum current: 8.5; 4.3 A max 12; 6.8 A max 15.5; 10 A max 15.5; 10 A max
Frequency range: 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
PoE output wattage
(MAX)*:
275 W 900 W 1100 W 1400 W

HP zl2 Specifications

General

Manageable	Yes
Layer	Layer 3
Management	Web
Jumbo Frame Support	Yes
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Model	HP 24-Port 10/100/1000Base-T zl Module (J8702A)
