• LCD Control—Enables user to set LCD control
• Memory Information—Displays memory frequency and timing setting information
• Max TOLUD—Displays the maximum value of TOLUD
Intel IGD Configuration
• GOP Configuration—Displays GOP driver option
• GOP Driver—Enables GOP driver to unload VBIOS. Disable GOP driver to load BIOS.
• Integrated Graphics Device—Enables or disables Intel IGD. Enable when selected as the Primary
Video Adapter.
• IGD Turbo Enable—Enables or disables IGD turbo function
• Primary Display—Enables user to select which IGD/PCI graphics device should be the primary
display
• GFX Boost—Enables or disables GFX boost function
• PAVC—Enables or disables PAVC
• DVMT Pre-Allocated—Enables user to select DVMT 5.0 pre-allocated (fixed) graphics memory size
used by the IGD
• DVMT Total Gfx Mem—Enables user to select DVMT 5.0 total graphic memory size used by the IGD
• Aperture Size—Enables user to select the aperture size
• DOP CG—Enables or disables DOP clock gating
• GTT Size—Enables user to select the GTT size
• IGD Thermal—Enables or disables IGD thermal
• Spread Spectrum clock—Enables or disables spread spectrum clock
• ISP Enable/Disable—Enables or disables ISP PCI device selection
• ISP PCI Device Selection—Enables user to select ISP PCI. Default ISP is PCI B0D2F0 for Windows
Boot. Perform Linux Boot to select B0D3G0.
• VCC_Vnn for Power State2—Enables or disables VCC_Vnn power state2
Graphics Power Management Control
RC6 (Render Standby)—Enables or disables render standby support
LCD Control
• Primary IGFX Boot Display—Enables user to select the video device that will be activated during
POST. VGA mode is only supported on primary display.
• LVDS Panel Type—Enables and selects LCDS type or disables LVDS function
South Bridge sub-menu options
• Azalia HD Audio —Displays Azalia HD audio options
• USB Configuration —Displays USB configuration settings
• PCI Express Configuration —Displays PCI Express configuration settings
• LPSS and SCC Devices Mode—Displays LPSS and SCC device mode settings
• LAN1 Control—Enables or disables LAN1
◦ LAN1 PXE Option ROM—Enables or disables boot option for LAN1 Controller
• LAN2 Control—Enables or disables LAN2
◦ LAN2 PXE Option ROM—Enables or disables boot option for LAN2 Controller
• Global SMI Lock—Enables or disables SMI lock
• BIOS Read/Write Protection—Enables or disables BIOS SPI region read/write protect
38 Intel IGD Configuration
