LPQ58/80 User Manual
Rev 1.0 www.hprt.com
10
Instructions>>.
 The movable paper sensor must be fastened in the correct position to make sure that paper
sensor can detect the paper status and label location under label printing mode.
 Correct position: the little triangle on movable paper sensor frame must be opposite to the one
on the printer guide frame.
Figure 3-7
4. After entering density setting mode, it prints the following contents:
Setting density:
Density: middle
If user want to change the density, press【POWER】 button to select. Press 【POWER】 button one
time, and the printer prints the current density : ***** . When the printer shows the density
required, press 【FEED】 button to confirm and quit. The printer enters the forth setting – print
width setting.
Optional density: high, middle and low.
5. After entering print width setting mode, it prints the following contents:
Set print width mode:
Print width: default
If user want to change the print width, press 【POWER】 button to select. Press 【POWER】 button
one time, and the printer prints the current print width ***** . When the printer shows the print
width required, press【FEED】button to confirm and quit.The printer enters the fifth setting – print
protocol setting.
Optional printing width: default (384dots) and full area (448dots).
