ENGLISH
12 V DC to 230 V AC Soft Start Power Inverter
24 V DC to 230 V AC Soft Start Power Inverter
4000 WATT CONTINUOUS OUTPUT POWER
SPECIFICATION
Specs. DC 12 V DC 24 V
Output power 4000 W continue 4000 W continue
8000 W surge output 8000 W surge output
Input voltage DC 10 ~ 16 V DC 20 ~ 30 V
Output voltage AC 230 V AC 230 V
Output waveform Modied sine wave Modied sine wave
Output frequency 50 or 60 Hz 50 or 60 Hz
Standby current < 1 A < 0.8 A
Efciency 85% ~ 90% 85% ~ 90%
High voltage input shutdown DC 16 V +/- 0.5 V DC 31 V +/- 0.8 V
Battery low alarm DC 10.5 V +/- 0.5 V DC 21 +/- 0.8 V
Battery low shutdown DC 10 +/- 0.5 V DC 20 +/- 0.8 V
Thermal protection 60 +/- 5°C 60 +/- 5°C
Cooling Temperature controlled fan Temperature controlled fan
Protection * Output short
* Input polarity reverse (by fuse)
* High DC input voltage
* Battery low alarm
* Battery low shutdown
* Overload
* Over temperature
Fuse 30 A * 18 pcs 15 A * 18 pcs
AC outlet Two Two
Size ( LxWxH ) 580x210x159 mm 580x210x159 mm
Weight 11.2 kg 11.2 kg
INSTALLATION
Mount the inverter horizontally or vertically on a at surface.
CAUTION!
Ensure these instructions are followed when installing the inverter:
1. Make sure the inverter stays dry.
2. The inverter should be installed in a cool place, ambient temperature between 0°C and 25°C.
3. To avoid re hazard and overheating, do not cover or obstruct the ventilation openings of the
inverter. Regularly check the ventilation openings as they collect dust and dirt. Also keep at
least 2.5 cm space around the inverter for air ow.
4. To avoid risk of re and explosion, please do not install the inverter close or next to ammable
substances or batteries.
5. Install the inverter out of reach of children.
