7.
Insert the manifold gasket
8.
Connect the connector to the encoder reader,
ensuring the black wire is on the right
9.
Insert the encoder cable manifold in the
appropriate cavity
10.
Block the encoder electrical box with four 4x25
lowered head screws, using Loctite 510 and a
copper washer
