HSD ES915 - Button for Manual Command of Tool Release

HSD
5801H0056 _______________________________________________________________ 56/181
H1423H0262 Rev.02 (SP 120.150.4A )
Rated voltage (*)
V 380 380 380 380 380
Rated frequency Hz 267 333 500 600 733
Rated speed rpm 8,000 10000 15,000 18,000 22000
Duty type
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
S1
cont
S6
60%
Rated power kW 16.0 18.0 16.0 18.0 11.0 13.0 8.0 10.0 4.3 5.2
Rated torque Nm 19 21.5 15.3 17.2 7.0 8.3 4.2 5.3 1.9 2.3
Rated current A 34.5 45 34.5 45 23.7 32.6 18.0 26.0 8.0 11.0
Rated output η 0.8
Power factor cos φ 0.7
Number of poles 4.0
Type of insulation F
IP rating 54
Type of cooling Raffreddamento a liquido / Flüssigkeit / Liquid cooling
Weight of
LONG NOSE version
kg ~ 45
[(*) supplied by inverter]
