HSM ProfiPack C400 - Transportation and Installation; Machine Overview; Key Components; Display and Control Panel

08/2018 ProPack C400 9
1 Feed opening
2 Safety notice
3 Warning sticker / type plate
4 Operator control panel
5 Limit stop
6 “Padding”ap
4 Overview
43
5
HSM GmbH + Co. KG
Austrasse 1-9
88699 Frickingen / Germany
1
2
6
5 Display and control panel
1 Forwardbutton
2 Stop button
3 Reverse button
4 “Ready for operation” display
5 “Blockage”display
3 Transportation and installation
Connectthepowercabletothemachine.
Themachinemustbeconnectedtoapower
sourcewhichmeetsthespecicationsonthe
nameplate.Makesurethatthepowercable
is unobstructed and that nobody can tread
on it. Plug the connecting plug of the ma-
chine into a properly installed socket.
Use the recessed grips at the sides to transport
the shredder.
english
1
3
2
4 5
