16 SECURIO B 22 12/2014
english
9 Technical data
Cutting type Strip cut Cross cut
Cut size (mm) 5.8 3.9 3.9 x 30 1.9 x 15
Security level DIN 66399 P-2 / O-2 / T-2
E-2
P-2 / T-2 / E-2 P-4 / T-4 / E-3
F-1
P-5 / T-5 / E-4
F-2
Cutting capacity* (sheets), A4 70 g/m
2
80 g/m
2
22 - 24
17 - 19
16 - 18
13 - 15
12 - 14
9 - 11
9 - 11
7 - 9
Cutting speed 80 mm/s 90 mm/s
Weight 11 kg 12 kg
Intake width 240 mm
Power supply 230 V, 50 Hz 110 V - 120 V, 60 Hz
220 V, 60 Hz 100 V, 50 - 60 Hz
Power with max. number of sheets 440 W
Energy consumption in standby mode < 2 Wh
Operating mode Continuous operation
Ambient conditions in operation:
Temperature
Relative humidity
Height above sea-level (MSL)
-10 °C to +25 °C
max. 90 %, without condensation
max. 2,000 m
Size W x D x H (mm) 375 x 310 x 600
Shredded material container volume 33 l
Sound pressure level emissions
(Idle running/ load)
57 dB(A) / 59 dB(A)
A-weighted sound power level (LWAd in
idle mode)
75.0 dB
* The maximum number of sheets (DIN A4, 70 g/m² or 80 g/m²), fed lengthways, which can be cut in one cycle. The
performance data is determined when the motor is cold and the cutting device is freshly oiled. A weaker mains voltage
or a different mains frequency to the one specifi ed could result in less sheet capacity and increased noise during op-
eration. The sheet capacity can vary depending on the structure and properties of the paper and on the way it enters.
This document shredder meets the applicable harmonisa on legisla on of the European Union:
• Low Voltage direc ve 2006/95/EU
• EMC direc ve 2004/108/EU
• RoHS direc ve 2011/65/EU
The EU declara on of conformity can be requested from the manufacturer.
