8-100 Periodic Maintenance and Adjustment
1. reservoir drain hose
6. After draining the coolant, thoroughly
flush the cooling system with clean tap
water.
7. Replace the coolant drain bolt washer if
it is damaged, install the coolant drain bolt,
and then tighten it to the specified torque.
8. Install the coolant reservoir hose.
9. Pour the recommended coolant into the
reservoir to the maximum level mark, and
then install the reservoir cap .
