8-144 Periodic Maintenance and Adjustment
3. Check to see if the internal splines on the front wheel hub, or the
outer splines of the front wheel axle are worn, abraded or damaged.
4. Check to be sure the rubber spring ring which connects the front
suspension and chassis is NOT damaged.
1. Check to see if the bearing in the rear axle bearing seat is damaged.
Rear wheels shake when
driving
2. Check to see if the moving bearing which connects the rear axle
bearing seat and swing arm is worn, abraded or loose.
3. Check to see if the retainer nut on the rear axles and/or rear wheels
are loose or damaged.
4. Check if the internal splines of rear wheel hub or the outer splines of
the rear axle are worn, loose or abraded.
5. Check if the rubber spring ring which connects the rear suspension
and chassis is damaged.
