5-21 Pre Operation Checks
1. Position indicator
2. High beam indicator
3. Mechanical parking lights
4. Neutral indicator “N”
5. Gear display
6. Brake fluidalarm indicator lights
7. Emergency indicator
8. Engine Oil-Pressure
9. Coolant temperature gauge
10. OBD Malfunction indicator lights
Low-Range Indicator Light “L”
This indicator light comes on when the drive select lever is in the “L” position.
Mechanical Parking Brake Indicator Light “ ”
This indicator light comes on when the mechanical parking brake is applied.
High-Range Indicator Light “H”
This indicator light comes on when the drive select lever is in the “H” position.
Neutral Indicator Light “N”
This indicator light comes on when the drive select lever is in the “N” position.
Reverse Indicator Light “R”
This indicator light comes on when the drive select lever is in the “R” reverse position.
OBD Malfunction Indicator Lights
When the engine fails, this malfunction indicator lights up.
