5-22 Pre Operation Checks
Coolant Temperature Warning Light “ ”
When the coolant temperature reaches a specified level, this light comes on to warn
that the coolant temperature is too hot. If the light comes on during operation, stop the
engine as soon as it is safe to do so and allow the engine to cool down for about 15
minutes.
CAUTION:
⚫ The engine may overheat if the vehicle is overloaded. If this happens, reduce the
load to specification.
⚫ After restarting, make sure that the light is out. Continuous use while the light is on
may cause damage to the engine.
High beam indicator
The light being on means headlight is at high beam mode.
Position light indicator
The light being on means that the position light fixed in the front headlight has been
turned on.
Emergency indicator“ ”
The light being on means emergency lamp is on.
Use of EPS system If Equipped
The Meter is an important part of TRACTOR.
The Meter works together with EPS system and monitors the working condition of EPS
system.
A fault will be displayed by fault indicator light and fault indicator of EPS system, so the driver
can acknowledge a fault within the EPS system and take the appropriate measures.
When a fault occurs in the EPS system, the fault indicator light will illuminate. At the same
time, fault indicator of EPS system will display the fault code for maintenance.
⚫ If the fault indicator light is illuminated stop the TRACTOR and turn the TRACTOR
to the off position. After a few moments turn the TRACTOR to the on position and
see if the EPS indicator light is still illuminated.
⚫ If the EPS indicator light is not illuminated the TRACTOR can be ridden.
⚫ In the fault indicator light remains illuminated take the TRACTOR to an authorized
repair center for maintenance.
Speedometer Unit
