8-92 Periodic Maintenance and Adjustment
Tightening torque:
Final gear oil drain bolt:
23 Nm (2.3m·kgf, 17ft·lbf)
5. Fill the final gear case with the specified
amount of the recommended oil.
Recommended oil:
SAE 80 API GL-4 Hypoid gear oil
Oil quantity:
0.25 L (0.22 Imp qt, 0.26 US qt)
CAUTION:
Be sure no foreign material enters the final
gear case.
6. Install the filler bolt and tighten it to the
specified torque.
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3m·kgf, 17ft·lbf)
7. Check for oil leakage. If oil leakage is
found, check for the cause.
Differential gear oil
Checking the differential gear oil
1. Place the TRACTOR on a level surface.
