8-93 Periodic Maintenance and Adjustment
2. Remove the differential gear oil filler bolt
and check the oil level. It should be up to
the brim of the filler hole. If the level is low,
add sufficient oil of the recommended type
to raise it to the specified level.
1. Differential gear oil 2. Differential gear oil filler bolt
3. Correct oil level
CAUTION:
Be sure no foreign material enters the
differential gear case.
3. Install the differential gear oil filler bolt,
and then tighten it to the specified torque.
Tightening torque:
Differential gear oil filler bolt:
23 Nm (2.3m·kgf, 17ft·lbf)
