8-94 Periodic Maintenance and Adjustment
1. Place the TRACTOR on a level surface.
2. Place a container under the differential
gear case to collect the used oil.
3. Remove the differential gear oil filler bolt
and differential gear oil drain bolt to drain
the oil.
1. Differential gear oil drain bolt
4. Install the differential gear oil drain bolt
and tighten it to the specified torque.
Tightening torque:
Differential gear oil drain bolt:
10 Nm (1.0m·kgf, 7.2ft·lbf)
