7. TECHNICAL SPECIFICATIONS
7.1. TECHNICAL CHARACTERISTICS
Accuracy calculated as [%reading + (no. digits*resolution)] at 23°C 5°, <80%HR
DC Voltage (Autorange)
Range
[V]
Resolution
[V]
Accuracy
Input
impedance
Overload protection
0.0  690.0
0.1
(0.5%rdg + 2digits) 1M
690VDC/ACrms
AC, AC+DC, LoZ TRMS Voltage (Autorange)
Range
[V]
Resolution
[V]
Frequency Accuracy
Protection against
overcharge
0.5  690.0
0.1 32Hz ÷ 1kHz
(0.5%rdg + 2sigits)
690VDC/ACrms
Input impedance function VAC: 1M,
Input impedance LoZ: 3.5k for 10s (@ 110V/50Hz), 4.5s (@ 230V/50Hz), 1s (@ 400V/50Hz). For higher voltage
values, the input impedance increase to 10k. CAUTION: do not leave the instrument connected for more than 1
minute
Automatic selection DC mode, Max crest factor: 1.5
Current and voltage frequency (Autorange)
Range [Hz] Resolution [Hz] Accuracy
33.00  99.99
0.01
(0.1%rdg +1digit)
100.0  999.9
0.1
Voltage range: 0.5V ÷ 690V, Current field: 0.5A ÷ 3000A (Flexible clamp F300U), 1mV ÷ 1000mV (STD clamp)
AC TRMS current (Flexible clamp F3000U) – (Autorange)
Range [mV] Resolution [mV] Accuracy
1  3000
1
(0.5%rdg + 2digits)
Max crest factor: Frequency bandwidth: 1kHz
AC TRMS Current (Flexible clamp FS 1V), DC, AC, AC+DC (STD clamp) – (Autorange)
Range [mV] Resolution [mV] Accuracy
1  1000
1
(0.5%rdg + 2digits)
Max crest factor: Frequency bandwidth: 1kHz
INRUSH AC TRMS Current (Flexible clamp F3000U)
Range [mV] Resolution [mV] Accuracy (*)
1  3000
1
(2%reading + 2digits)
(*) Accuracy declared for frequency: DC, 42.5 ÷ 69Hz
Max crest factor: 3,
Sampling frequency: 4kHz
Response time: 1ms (Peak), 16.7ms, 20ms, 50ms, 100ms, 150ms, 175ms, 200ms (max RMS)
INRUSH AC TRMS Current (Flexible clamp FS 1V), DC, AC, AC+DC (STD clamp)
Range [mV] Resolution [mV] Accuracy (*)
1  1000
1
(2%reading + 2digits)
(*) Accuracy declared for frequency: DC, 42.5 ÷ 69Hz
Max crest factor: 3,
Sampling frequency: 4kHz
Response time: 1ms (Peak), 16.7ms, 20ms, 50ms, 100ms, 150ms, 175ms, 200ms (max RMS)
Resistance and continuity test (Autorange)
Range [] Resolution []
Accuracy Buzzer
0.0  199.9
0.1
(1.0%reading +
5digits)
<30
200  1999
1
