JUPITER
IT - 36
Reference standards
Instrument safety: IEC/EN61010-1,IEC/EN61010-2-030,
IEC/EN61010-2-033
EMC: IEC/EN 61326-1
Test RCD: IEC/EN61557-6
Test LOOP P-P, P-N, P-PE, Ra : IEC/EN61557-3
Phase sequence: IEC 61557-7
Insulation: double insulation
Pollution level: 2
Measurement category: CAT IV 600V, CAT III 690V to earth and
between inputs
7.1.1. General characteristics
Mechanical characteristics
Size (L x W x H): 175 x 85 x 55mm (7 x 3 x 2in)
Weight (batteries included): 420g (15 ounces)
Mechanical protection: IP40
Power supply
Battery type: 4x1.5V batteries type AAA IEC LR03
Low battery indication: symbol “” ” on the display
Battery life: V, A, , approx. 132h (backlight OFF)
V, A, , approx. 68h (backlight ON)
Ra (15mA) approx. 5400 tests (backlight ON)
Ra (100mA) approx. 13k tests (backlight ON)
RCD approx. 8600 tests (backlight ON)
RCD T approx. 160k tests (backlight ON)
Auto Power Off: after 15 minutes’ idling (can be disabled)
Display
Type of display: 4 dgt LCD, max 9999 dots, decimal sign, point
backlight and bargraph, indication of polarity
Sampling frequency: 2 times/s
Conversion: RMS
7.2. ENVIRONMENTAL CONDITIONS FOR USE
Reference temperature: 23°C 5°C (73°F ± 41°F)
Operating temperature: 5°C ÷ 40°C (41°F ÷ 104°F)
Allowable relative humidity: <80%RH
Storage temperature: -20°C ÷ 60°C (-4°F ÷ 140°F)
Storage humidity: <80%RH
Max operating altitude: 2000m (6562ft)
This instrument satisfies the requirements of Low Voltage Directive 2014/35/EU
(LVD) and of EMC Directive 2014/30/EU
This instrument satisfies the requirements of European Directive 2011/65/EU (RoHS)
and 2012/19/EU (WEEE)
7.3. ACCESSORIES
See the attached packing list.
