PV-ISOTEST
EN - 34
10. TECHNICAL SPECIFICATIONS
10.1. TECHNICAL CHARACTERISTICS
Accuracy is indicated as [%reading + (no. of digits) * resolution] at 23°C ± 5°C, <80%RH
DC Voltage
Range [V] Resolution [V] Accuracy
3 1500
1
(1.0reading + 2digits)
AC TRMS Voltage
Range [V] Resolution [V] Accuracy
3 1000
1
(1.0reading + 3digits)
Frequency range: 42.5 ÷ 69Hz ; Voltages zeroed for measured value <3V
Insulation Resistance (M) R(+), R(-), Rp – DUAL mode
Test voltage DC [V]
Range [M
] Resolution [M]
Accuracy (*)
250, 500, 1000, 1500
0.1
0.99
0.01
(5.0
reading + 5digits) 1.0 19.9
0.1
20 100
1
(*) Accuracy given for VPN≥240V, Rfault≥10
. Accuracy of Rp and R(+) not declared if R(+)≥0.2M
and R(-)<0.2M
, Accuracy of
Rp and R(-) not declared if R(+) <0.2M
and R(-) ≥0.2M
Open circuit voltage <1.25 x rated test voltage
Short-circuit current <15mA (peak) for each test voltage
Rated test current > 1mA on R = 1k x Vnom (with VPN, VPE, VNE= 0)
Insulation resistance (M) – TIMER mode
Test voltage DC [V]
Range [M
] Resolution [M]
Accuracy
250, 500, 1000, 1500
0.01
9.99
0.01
(5.0
reading + 5digits)
10.0 99.9
0.1
Open circuit voltage <1.25 x rated test voltage
Short-circuit current < 15mA (peak) for each test voltage
Rated test current > 1mA on R = 1k x Vnom (with VPN, VPE, VNE= 0)
Selectable Timer: 3s ÷ 999s
Continuity of protective conductors (RPE)
Range [] Resolution []
Accuracy
0.00 9.99
0.01
(2.0
reading + 2digits) 10.0 99.9
0.1
100 1999
1
Test current: >200mA DC up to 5 (cables included), resolution 1mA, accuracy (5.0%reading + 5digits)
Open-circuit voltage 4 < V
0
< 10V
GFL – Ground Fault Locator
Test voltage DC [V]
Range [M] Resolution [M]
Accuracy Rp(*)
Position
accuracy
250, 500, 1000, 1500
0.1 0.99
0.01
(5.0rdg + 5dgt) 1module
1.0 19.9
0.1
20 100
1
(*) Accuracy given for VPN≥240V, Rfault≥10
. Accuracy of Rp and R(+) not declared if R(+)≥0.2M
and R(-)<0.2M
, Accuracy of
Rp and R(-) not declared if R(+) <0.2M
and R(-) ≥0.2M
Open circuit voltage <1.25 x rated test voltage
Short-circuit current <15mA (peak) for each test voltage
Rated test current > 1mA on R = 1k x Vnom (with VPN, VPE, VNE= 0)
The GFL function allows obtaining correct results ONLY at the following conditions:
Test carried out on a single string disconnected from the inverter, any dischargers and functional ground connections
Single fault of low insulation located at any position in the string
Insulation resistance of the single fault <0.1M
Due to the random nature of these faults, it is recommended to carry out the measurements in environmental conditions similar to
those in which the fault was reported
