65
LP- 293 REV. 9.2.14
FLAME 0.0uA
FAN SPEED 3497 RPM
This screen displays the boiler flame current on the top line. The second line displays the fan speed in the
boiler.
The top line displays the voltage on the optional input. This voltage is only relevant if an external 0-10 volt
signal is being used to control the boiler.
This display shows the status of the communication bus between multiple boilers. If the boiler is in a single
boiler configuration, the display will show ‘NO CONN’. If the boiler is used in a multiple coiler configuration, is
the Master Boiler, and other boilers are connected to the communication bus and powered, this screen will
show the address of each boiler connected to the bus.
The top line of this display indicates the amount of hours the boiler has had power applied to it over its life.
The second line indicates how many hours the burner has been on for central heat demand over its life.
The top line of this display indicates the amount of hours the burner has been on for domestic hot water
demand in the life of the boiler. The second line indicates how many times the burner has successfully ignited
in the life of the boiler.
SYS CH ON 0h
SYS DWH ON 0h
This screen displays how many hours the boiler has run to meet central heat and DWH demand.
Table 22 – Boiler Control Status Menu Screens
The following 10 screens display the last ten boiler lockout faults. The faults are displayed from most recent to oldest by pressing the ▼
key.
FAULT HISTORY 1
07/27/2009 Mo 5:19A
This screen displays the last lockout fault the boiler controller had. The top line will alternate between the
words ‘FAULT HISTORY’ and the actual fault encountered. The bottom line displays the date and time the
fault occurred.
FAULT HISTORY 2
08/28/2009 Fr 5:19A
This screen displays the second oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the actual fault encountered. The bottom line will display
the date and time that the fault occurred.
FAULT HISTORY 3
08/28/2009 Fr 5:19A
This screen displays the third oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the actual fault encountered if one has occurred. The
bottom line displays the date and time a fault occurred.
FAULT HISTORY 4
08/28/2009 Fr 5:19A
This screen displays the fourth oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
FAULT HISTORY 5
08/28/2009 Fr 5:19A
This screen displays the fifth oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
FAULT HISTORY 6
08/28/2009 Fr 5:19A
This screen displays the sixth oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
FAULT HISTORY 7
08/28/2009 Fr 5:19A
This screen displays the seventh oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
FAULT HISTORY 8
08/28/2009 Fr 5:19A
This screen displays the eighth oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
FAULT HISTORY 9
08/28/2009 Fr 5:19A
This screen displays the ninth oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
FAULT HISTORY 10
08/28/2009 Fr 5:19A
This screen displays the tenth oldest lockout fault that occurred in the boiler controller. The top line will
alternate between the words ‘FAULT HISTORY’ and the fault encountered. The bottom line displays the date
and time the fault occurred.
Table 23 – Fault History Screens
