HTP InverArc 160 Plus - Page 5

5
Specifications
Input Power
120V, Single Phase, 50/60Hz
230V, Single Phase, 50/60Hz
Stick
TIG
Stick
TIG
Maximum Input
Amperage (A)
31.8
19.5
21.3
13.8
Effective Input
Power (A)
17.4
15.1
13.5
8.7
Power Factor
0.99
0.99
Output Amperage (A)
10 to 125
10 to 160
Max No-Load Voltage (V)
55 (80)
Duty Cycle (Stick & TIG)
30%@125A
60% @ 95A
100% @ 75A
60% @ 125A
100% @ 90A
40% @ 160A
60% @ 125A
100% @ 100A
Protection Class
IP23
Insulation Class
F
Dimensions (L x W x H)
14.37” x 5.51” x 9.06”
Weight
17.64 Lbs.
