Huahuan Electronics H20RN-2000.V2 Series User Manual

Hardware Description
H20RN-2000.V2 Series Platforms
2 Architecture and Introduction
Version 1.3(Oct.2019)
Beijing Huahuan Electronics Co., Ltd.
3
Card type
Card name
Slot limit
8GE card
GE08/GU08/GE08G/
GE08E/GU08E
Slot 3-8
16E1 emulation card
EC16
Slot 3-8
STM-1 interface
emulation card
SC01QE
Slot 3-8
-48V power card
PWR48150/PWR48
Slot PWR1, PWR2
220V power card
PWR22150/PWR22
Slot PWR1, PWR2
Fan card
FAN02
FAN slot
When 2*10GE card is inserted in slot 7, it only supports 1 10G interface.
Figure 2-2 The H20RN-2000L.V2 chassis slot allocation diagram
2
3 4
1
PWR1
PWR2
FAN
Table 2-2 The H20RN-2000L.V2 card configuration list
Card type
Card name
Slot limit
NM+PX card
MX01/PMX01
Slot 2
2×10GE card
XGE02/XGE02G
Slot 1, 3, 4
8GE card
GE08/GU08/GE08G/G
E08E/GU08E
Slot 1, 3, 4
16E1 emulation card
EC16
Slot 1, 3, 4
STM-1 interface
emulation card
SC01QE
Slot 1, 3, 4
NOTE
