Huahuan Electronics H20RN-2000.V2 Series User Manual

2 Architecture and Introduction
Hardware Description
H20RN-2000.V2 Series Platforms
20
Beijing Huahuan Electronics Co., Ltd.
Version 1.3(Oct.2019)
Technical Specifications
Table 2-15 lists technical specifications of the Ethernet cable.
Table 2-15 Technical specifications of the Ethernet cable
Item
Description
Connector type
RJ45 connector (crystal head)
Cable type
Category 5 unshielded twisted pair (UTP-5) or
shielded twisted pair (STP)
Color
Dark grey
Characteristic
impedance
100.0Ω
Inner conductor wire
diameter
0.510mm
Breakdown voltage
500.0V
Inner conductor DC
impedance
93.8Ω/km
Quantity of cores
8
Frequency range
0~100MHz
Frequency attenuation
22dB/100m@100MHz
2.3.4 AC Power Cable
Application
AC power cable transports AC power from power distribution equipment to AC power supply
socket, and then transmits power to the entire device.
The selections of AC power cables are different according to local standards, as shown in Table
2-16.
