Huahuan Electronics H20RN-2000.V2 Series User Manual

Hardware Description
H20RN-2000.V2 Series Platforms
4 Appendix1 General Card Introduction
Version 1.3(Oct.2019)
Beijing Huahuan Electronics Co., Ltd.
35
Figure 4-2 NM+PX card (PMX01)
PMX01
RUN
MA
ALM
NM CONSOLE
RST
BUSY
BITS 1PPS TOD
1 2 3 4
CTRL
1 2 3 4
DIP ON↓
ALM/ALMO
4.3 2×10GE Card (XGE02/XGE02G/TU02)
2×10GE card is a 10GE optical port card. It provides 2 10GE optical ports, each of which has
one LINK LED.
Figure 4-3 2×10GE card (XGE02)
XGE02G
LINK
XGE1
XGE2
Figure 4-4 2×10GE card (XGE02G)
XGE02G
LINK
XGE1
XGE2
Figure 4-5 2×10GE card (TU02)
TU02
LINK
XGE1
XGE2
4.4 8GE Card (GE08/GE08G/GU08)
8GE card provides 8 GE optical ports, each of which has one LINK LED.
Figure 4-6 8GE card (GE08)
LINK
GE1 GE2 GE7 GE8GE5 GE6GE3 GE4
GE08
