Hardware Description
H20RN-2000.V2 Series Platforms
2 Architecture and Introduction
Beijing Huahuan Electronics Co., Ltd.
Table 2-10 RJ-45 socket definition at NM port
Table 2-11 RJ-45 socket definition at Console port
DIP Control
On the H20RN-2000.V2 series platforms, MX01/PXM01 card provides 1 group of 4-position DIP
switches, the definitions of DIP switches are shown in Table 2-12. The “ON” in the table is the
ON in the DIP switch.
Table 2-12 4-position DIP switches setting mode
Switch down (ON): zero-touch configuration
Configuration synchronization
Power Port
The device uses dual ~220V AC, dual -48V DC and ~220V AC+-48V DC for power supply. It
supports 1+1 protection and online replacement. Users can select the power type according to
their needs.
For ~220V AC power supply, connect IEC compliant power cord to ~220V AC power socket for
power connection, and the middle electrode of the AC power socket is protection ground.
