Connecting the Cables
Matched Box Series Endpoints
Example:
The Camera 200 is connected to HUAWEI Box 500 directly through an HDMI
cable or an HDMI cable adapter.
HDMI connection:
Weight bearing minimum of 8.5 kg (18.74 lb) and a thickness between 2
mm (0.08 in.) to 3 mm (0.12 in.)
A location pillar which can be inserted into the location hole of the Camera
200. The distance between the screw hole on the bracket and location pillar
must be 14.5 mm (0.57 in.) to match the holes of the Camera 200.
If the bracket has a front side and back side, the location pillar must be
placed on the front, and the screw hole on the back.
A screw hole and one 1/4"-20UNC screw (using UNC screw included with
purchased ceiling bracket recommended to avoid mismatch)
Others
Install the camera on a tripod (not included).
