Item Description
Maximum
number of
concurrent
users
≤ 64
Maximum
transmit
power for
each radio
17 dBm
NOTE
The actual transmit power depends on local laws and regulations.
You can adjust the transmit power from the maximum transmit power by 20 dB, with a
step of 1 dB. The adjustment range varies according to AP models.
Maximum
number of
non-
overlapping
channels
2.4 GHz
802.11b/g
l 20 MHz: 3
802.11n
l 20 MHz: 3
l 40 MHz: 1
5 GHz
802.11a
l 20 MHz: 24
802.11n
l 20 MHz: 24
l 40 MHz: 11
NOTE
The number of non-overlapping channels
varies in different countries. For details,
see the Country Code & Channel
Compliance Table
CAUTION
If the AP is delivered to the USA, pay
attention to the following on channel and
frequency band usage.
1. The country code of the AP is fixed.
2. The frequency band ranging from
5.15 GHz to 5.25 GHz can only be
used indoors.
3. High power radars working at
frequencies in the range of 5.25 GHz
to 5.35 GHz, 5.47 GHz to 5.6 GHz,
and 5.65 GHz to 5.725 GHz can
interfere with or even damage APs
working at the same frequency.
4. APs cannot work at channels in
frequencies ranging from 5.6 GHz to
5.65 GHz or their overlapping
channels.
Channel rate
supported by
the
AP3010DN-
AGN
802.11b: 1, 2, 5.5, and 11 Mbit/s
802.11g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s
802.11n data rate(2.4 GHz and 5 GHz):
GI
a
= 800 ns
GI = 400 ns
20 MHz (Mbit/s) 40 MHz (Mbit/s) 20 MHz (Mbit/s) 40 MHz (Mbit/s)
6.5 @ MCS
b
0
13.5 @ MCS0 7.2 @ MCS0 15 @ MCS0
13 @ MCS1 27 @ MCS1 14.4 @ MCS1 30 @ MCS1
19.5 @ MCS2 40.5 @ MCS2 21.7 @ MCS2 45 @ MCS2
26 @ MCS3 54 @ MCS3 28.9 @ MCS3 60 @ MCS3
39 @ MCS4 81 @ MCS4 43.3 @ MCS4 90 @ MCS4
52 @ MCS5 108 @ MCS5 57.8 @ MCS5 120 @ MCS5
Huawei AP3010DN-AGN Access Points
Product Description 4 Technical Specifications
Issue 01 (2013-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
17
