Huawei AP8030DN

Issue 05 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
23
AP8030DN
Product Description
5 Technical Specifications
5Technical Specifications
5.1 Basic Specifications
Table 5-1 Basic Specifications
Item
Description
Technical
specifications
Dimensions (H x W
x D)
100 mm x 290 mm x 260 mm
Weight
3.6 kg
System memory
256 MB DDR3
64 MB Flash
Power specifications
Power input
PoE power supply in compliance with IEEE
802.3at
Maximum power
consumption
20.1 W
NOTE
The actual maximum power consumption
depends on local laws and regulations.
Environment
specifications
Operating
temperature
-60 m to 1800 m: -40°C to +65°C
1800 m to 5000 m: Temperature decreases
by 1°C every time the altitude increases 300
m.
Storage temperature
-40°C to +70°C
Operating humidity
0% to 100% (non-condensing)
IP rating
IP67
Wind resistance
Up to 149 MPH
Atmospheric
pressure
53 kPa to 106 kPa
