Huawei AP8030DN

Issue 05 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
AP8030DN
Product Description
2 Hardware Structure
2Hardware Structure
2.1 AP8030DN
Appearance
Figure 2-1 shows the appearance of the AP.
NOTE
The actual device appearance may be different from the following device appearance, but these
differences will not affect device functions.
Figure 2-1 AP appearance
