Huawei Ascend G620S User Manual

3
Getting started
Do not block the area around the ambient light and proximity sensor.
When you attach a protective film to the screen, make sure it does not
block the sensor.
Buttons
Inserting the micro-SIM card
• Your phone supports only standard micro-SIM cards. Do not use any
other sizes as they may damage your phone. To replace or purchase a
micro-SIM card, contact your service provider.
• The dimensions of a standard micro-SIM card are 15 mm x 12 mm x
0.76 mm (0.59 in. x 0.47 in. x 0.03 in.).
Make sure your phone is turned off before you insert the micro-SIM card.
Return
• Touch to return to the previous screen or exit the
current application.
• When you are entering text, touch to hide the
onscreen keyboard.
Home Touch to return to the home screen.
Menu
• Touch to display an option menu.
• Touch and hold to display the list of recently used
applications.

Huawei Ascend G620S Specifications

General

Display Size	5.0 inches
Resolution	720 x 1280 pixels
Processor	Quad-core 1.2 GHz Cortex-A53
RAM	1 GB
Internal Storage	8 GB
Expandable Storage	microSD, up to 32 GB
Rear Camera	8 MP
Front Camera	2 MP
Battery Capacity	2000 mAh
Operating System	Android 4.4.2 (KitKat)
Status	Discontinued
Technology	GSM / HSPA / LTE
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 900 / 2100
Speed	HSPA 42.2/5.76 Mbps, LTE Cat4 150/50 Mbps
GPRS	Yes
EDGE	Yes
Weight	160 g (5.64 oz)
SIM	Micro-SIM
Type	IPS LCD
Multitouch	Yes
Chipset	Qualcomm MSM8916 Snapdragon 410
CPU	Quad-core 1.2 GHz Cortex-A53
GPU	Adreno 306
Video	1080p@30fps
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 b/g/n, hotspot
Bluetooth	4.0, A2DP
GPS	Yes, with A-GPS, GLONASS
Radio	FM radio
USB	microUSB 2.0
Sensors	Accelerometer, proximity
Messaging	SMS(threaded view), MMS, Email, Push Email, IM
Browser	HTML5
Java	No
Colors	Black, White
4G bands	LTE band 3(1800), 7(2600), 20(800)
Dimensions	142.9 x 72 x 8.5 mm
Primary Camera Features	LED flash
