2 Connecting Cables
1 Telephone jack on the
wall
2 Splitter 3 Telephone
4 STB 5 Desktop computer 6 Power adapter
7 USB device 8 Laptop computer
a Line port b Telephone port c Modem port
NO TE
Some accessories are not delivered with the DG8045-50. Prepare them by yourself.
DG8045-50
Quick Start 2 Connecting Cables
