Huawei E8231 Product Description

HUAWEI E8231 HSPA+ Wingle V100R001
Product Description
Issue 03(2013-08-05)
Commercial in Confidence
Page 8 of 24
2.2 Technical Specifications
2.2.1 Hardware
Table 2-1 lists the hardware specifications.
Table 2-1 Hardware specifications
Item
Specifications
Technical standard
GSM/GPRS/EGPRS R99
WCDMA/HSDPA R5, HSUPA R6, HSPA+ R7
WLAN: IEEE 802.11b/g/n
Operating frequency
HSPA+/HSPA/UMTS
2100MHz (E8231s-1),
2100/900MHz(E8231s-2)
EDGE/GPRS/GSM: 1900MHz/1800MHz/900MHz/850MHz
WLAN：2412MHz～2472MHz
Maximum
transmitter power
WCDMA/HSPA+：+24dBm (Power Class 3)
GSM/GPRS 850M/900MHz： +33dBm (Power Class 4)
GSM/GPRS 1800MHz/1900MHz： +30dBm (Power Class 1)
EDGE 850M/900MHz： +27dBm (Power Class E2)
EDGE 1800MHz/1900MHz： +26dBm (Power Class E2)
WLAN:
802.11b：13（＋/-3）dBm
802.11g：11（＋/-3）dBm
802.11n：11（＋/-3）dBm
Static receiver
sensitivity
WCDMA/HSPA/HSPA+: Compliant with 3GPP TS
25.101(R7)
GSM/GPRS/EDGE: Compliant with 3GPP TS 05.05 (R99)
WLAN：
802.11b：-85（＋/-3）dBm
802.11g：-71（＋/-3）dBm
802.11n：-70（＋/-3）dBm
WLAN speed
802.11b: up to 11Mbit/s
802.11g: up to 54Mbit/s
802.11n: supporting MCS0～MCS7, up to 72.2Mbit/s
Maximum power
consumption
3W
