User Manual
EchoLife HG510 Home Gateway Chapter 2 Hardware Description
Huawei Technologies Proprietary
2-2
Table 2-1 lists the LED indicators.
Label Color Function
ALARM Red
Flashes on/off rapidly during the training
mode
Flashes on/off slowly: No ADSL link
Off: The ADSL link is established and active
ADSL
LINK
Green
On: The ADSL link is established and active
Off: No ADSL link
ADSL
ACT
Green
Flashes during ADSL data transfer
On: No data transfer
LAN1-4 Green
On: The LAN link is established and active
Off: No LAN link
Flashes during data transfer
PWR Green
On: The device is powered on
Off: The device is powered off
2.2 Rear Panel
The rear panel provides ports for the HG510 to receive/send data
and get power supply.
Table 2-2 lists ports function
Label Function
ADSL
RJ-11 connector: connects the device to a
telephone jack using the supplied cable
On/Off
Switches the device on and off
