Huawei EchoLife HG8145V5 User Manual

2 Connecting Cables
NO TE
● The ber connector connected to the optical port on the wall varies depending on
actual conditions.
● To ensure normal use of bers, make sure that the ber bending radius is larger than 30
mm.
No.
Item Description
1 On/O Powers the ONT on or o.
2 Power Connects to a power adapter.
EchoLife HG8145V5
Quick Start for QR code 2 Connecting Cables
Issue 04 (2022-11-08) Copyright © Huawei Technologies Co., Ltd. 4

Huawei EchoLife HG8145V5 Specifications

General

Power Supply	12 V DC, 1.5 A
Antenna Gain	5 dBi
Operating Temperature	0°C to 40°C
Operating Humidity	5% to 95% (non-condensing)
GPON Interface	Class B+
Wavelength	Tx 1310 nm, Rx 1490 nm
Transmission Distance	Up to 20 km
Device Type	GPON Terminal
Wi-Fi Standard	IEEE 802.11b/g/n
Optical Splitter Ratio	1:128
