Huawei EchoLife HG8245W5-6T User Manual

4 Technical Specications
Product Function
HG8245W5-6T ● 4 Ethernet ports
● 2 POTS ports
● 1 USB port
● 2.4 GHz & 5 GHz Wi-Fi
● Power adapter input: See the nameplate on the adapter.
● System power supply: See the nameplate on the device.
● Ambient temperature: 0ºC to +40ºC
● Ambient humidity: 5%–95% (non-condensing)
● Dimensions (H x W x D): 32 mm x 200 mm x 127 mm (without external
antenna and pads)
● Weight: About 400g
● Maximum system power consumption: 18 W
EchoLife HG8245W5-6T
Quick Start for QR code 4 Technical Specications
Issue 05 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 8

Huawei EchoLife HG8245W5-6T Specifications

General

Device Type	GPON Terminal
Power Supply	12 V DC, 1.5 A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE + 1 POTS + 1 USB
Wi-Fi	802.11b/g/n/ac
Max. Wi-Fi Speed	1167 Mbps
Antenna Gain	5 dBi
