1 Placing the Device
NO TE
● Do not install the ONT outdoors or in an outdoor cabinet.
● The ONT can be mounted onto a wall or placed on a desk. Do not install the ONT in
other modes, such as ceiling.
● Keep 10 cm clearance on all sides to ensure adequate ventilation.
● It is recommended that the computer and ONT be put far away from electric appliances
that generate strong magnetic or electric
elds, such as microwave ovens.
Mounting an ONT on the desk
The gure below shows an ONT that is horizontally placed on a desk.
EchoLife HG8245W5-6T
Quick Start for QR code 1 Placing the Device
Issue 05 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 1

Huawei EchoLife HG8245W5-6T Specifications

General

Device Type	GPON Terminal
Power Supply	12 V DC, 1.5 A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE + 1 POTS + 1 USB
Wi-Fi	802.11b/g/n/ac
Max. Wi-Fi Speed	1167 Mbps
Antenna Gain	5 dBi
