For details about parameter settings, see the sip soft-parameter command in the
eSpace IAD Product Documentation. The following describes the common settings for
connecting to the IMS network.
TERMINAL(config)#advanced
TERMINAL(advanced-config)#sip soft-parameter auth-username name
/*The user name, not user ID, is used in authentication.*/
TERMINAL(advanced-config)#sip soft-parameter new-service-mode local
/*The IAD sends the Invite message to the SoftSwitch, and processes
the hookflash event.*/
TERMINAL(advanced-config)#sip soft-parameter support-telurl on
/*Enable the TelURL based on the requirements on the IMS side. The Tel
URL is an address format using the SIP protocol, which differs from
SIP URL.*/
TERMINAL(advanced-config)#exit
Step 7 (Optional) Configure the wildcard groups.
The IAD supports the function of registering with the SIP server on the IMS network as
the wildcard groups. A wildcard group functions as a substitute for the SIP users
belonged to the group on the IMS network. To configure the wildcard group, proceed
as follows:
1. Run the sip groupuser command to add a wildcard group. The wildcard group
attributes are as follows: The ID is 0, IMS Public User Identity (IMPU) is
+862821010000, IMS Private User Identity (IMPI) is
+862821010000@abc.def.com, and password for authentication is 123456.
TERMINAL(config)#sip groupuser 0 impu +862821010000 impi
+862821010000@abc.def.com password 123456
2. Allocate two SIP users configured on the IAD to the wildcard group whose ID is 0.
TERMINAL(config)#sip user 0 groupid 0
TERMINAL(config)#sip user 1 groupid 0
3. Run the display sip groupuser all command to view the registration result of the
wildcard group.
If registration state is set to registered, the wildcard group is registered
successfully, and the SIP number in the wildcard group can be used.
If the wildcard group is registered unsuccessfully, check the network connection
between the IAD and the IMS and check whether the IMPU, IMPI, and password
for authenticating the wildcard group have been set in the IMS. If the SIP number
in the wildcard group cannot be used to make calls, check whether the user number
is configured in the corresponding wildcard group in the IMS.
Step 8 Configure the SIP user.
For details about mapping between user cable colors and ports, see in the Appendix.
Run the sip user command to configure SIP users for port 0 and port 1.
TERMINAL(config)#sip user 0 id +8657143210001 password 123456 name
+8657143210001@abc.def.com
