TERMINAL(config)#sip user 1 id +8657143210002 password 123457 name
+8657143210002@abc.def.com
The SIP user information on the IAD can be registered with the SIP server only after the SIP
user information has been configured on the SIP server.
Run the display sip attributeport-number command to view the configuration result.
After the registration is successful, two registered users can talk with each other. For
example, if the phone connected to port 1 dials 21010300, the phone connected to port
0 rings.
Number +8657143210002 consists of country code +86, area code 571, and local number
43210002. To make a local call, dial 21010300. The dialing rule is configured on the IMS
side.
Step 9 Run the write command to save the settings.
The command is:
TERMINAL(config)#write
----End
4.5 Accessing Network Through the IAD
A PC can access the network through the IAD101H, IAD102H, and IAD104H.
For example, to configure a PC to access the network through the IAD102H, do as
follows:
1. Connect the PC to the LAN port of the IAD, and the WAN port to the uplink, as
shown below.
