4.4 Connecting to the IMS (SIP)
The IAD101H/102H/104H can connect to the IMS directly or through SoftSwitch. If
the IAD connects to the IMS through SoftSwitch, configure the IAD according to the
scenario where the IAD connects to the IP PBX. This topic describes the scenario
where IAD users directly register with the IMS. After configuring data on the IMS,
configure the IAD101H/102H/104H so that the IAD101H/102H/104H can provide
voice services, including basic call and fax services.
Data Plan
You can obtain the connection data between the IAD and the IMS from the network
carrier or network administrator. The following describes how to enable the voice
function for an IAD101H/102H/104H user.
Table 4-5 Connection data between the IAD and the IMS
Item
Value
Parameter and Value on the
IAD
Control protocol
used between the
IMS and the IAD
SIP protocol
Protocol mode: SIP
IP address of the
SBC server
192.169.1.40/255.255.25
5.0
IP address of the SIP server:
192.169.1.40
NOTE
The IP address of the SIP server
is the IP address of the P-CSCF
or SBC. Set the parameter based
on the site requirements.
IP address of the
IAD
192.169.1.62/255.255.25
5.0
IP address of the IAD:
192.169.1.62/255.255.255.0
NOTE
The IAD must be able to ping the
SIP server.
SIP signaling port
number on the IAD
5060
Server port number: 5060
SIP signaling port
number on the IAD
5060
Local port number: 5060
Domain name of
the IAD
abc.def.com
User domain name: abc.def.com
NOTE
The user domain name must be
unique.
