3 Function Description
HUAWEI
16
4
(1)
(2)
(3)
(4)
(5)
1) Hook 2) Wall-mounting bracket 3) Spare battery case
4) Tapping screw installation hole 5) Wall-mounting bracket installation area
Figure 3-2 FWT back view (1)
(1)
1) Installation interface to indoor antenna
Figure 3-3 FWT back view (2)
Hook
It is used when the FWT is installed vertically.
Wall-mounting bracket
If you want to install the FWT vertically, you should install the wall-mounting
bracket in the corresponding installation area. For the details, refer to the "Wall
Mounting Mode".
Spare battery case
Spare battery should be placed in it.
