Category Default Value Value Range Setting
100/57V-115/66V-120/70V-208/120V-220/127V-230/132V-240/138V-
277/160V-347/200V-380/220V-400/230V-415/240V-440/254V-480/277V
Rates frequency 50 Hz 50Hz, 60Hz 50 Hz
Number of phase LN1 3 phases with N 3 phases with N/ 3 phases without N/ 1 phase 3 phases with N
Number of phase LN2 3 phases with N 3 phases with N/ 3 phases without N/ 1 phase 3 phases with N
Presence of external voltage Absent Absent/Present Absent
Primary voltage TV 690/400V
100V/57V-115V/66V-120V/70V-208V/120V-220V/127V-230V/132V-
240V/138V-277V/160V-347V/200V-380V/220V-400V/230V-415V/240V-
440V/254V-480V/277V-500V/288V-550V/317V-600V/347V-660V/380V-
690V/400V-910V/525V-950V/550V-1000V/577V-1150V/660V
Secondary voltage TV 400/230 V
100V/57V-115V/66V-120V/70V-208V/120V-220V/127V-230V/132V-
240V/138V-277V/160V-347V/200V-380V/220V-400V/230V-415V/240V-
440V/254V-480V/277V
2CBs/3CBs NPL opening only/3CBs NPL opening&closing/3CBs NPL
BusTie/3CBs Bus Tie
Generator not in use Generator not in use/Generator in use Generator in use
Line LN1 Line LN1/Line LN2/No priority Line Line LN1
With inverse procedure With inverse procedure/Without inverse procedure With inverse procedure
Min voltage threshold -15% -30%–-5% -15%
Max voltage threshold +15% +5%–+30% +15%
Min frequency threshold -1% -10%–-1% -1%
Max frequency threshold +1% +1%–+10% +1%
Digital Input DI10-function Generator Start disabled/generator start/logic enabling/remote reset/emergency block disabled
Digital Input DI10-type NO NO/NC NO
Digital Input DI8-type NO NO/NC NO
Modbus Baud Rate 9600 9600/19200/38400bps 9600
Modbus Parity absent even, odd, absent absent
mode local local, remote local
0s Always On, 0..59s, step 1s,1,2,3...30min, step 1min Always On
Chinese English/Italian/German/French/Spanish/Finnish/Russian/Chinese English
ABB ATS022 Initial Configuration Parameters
