Huawei HG531 V1 Quick Start

2
2 Powering On
To power on the HG531 V1, press its power button.
After the HG531 V1 is powered on, the HG531 V1 indicator turns on. The following
table lists how the indicators behave when the HG531 V1 is operating correctly. If the
indicators do not behave as expected, ensure that everything is plugged in correctly.
Indicator Expected State Description
Power Steady green The HG531 V1 is powered on.
ADSL
Blinking green A DSL connection is being activated.
Steady green
A digital subscriber line (DSL) connection has been
set up and activated.
Internet
Blinking green
The HG531 V1 is connected to the Internet in router
mode, and data is being transmitted.
Steady green
The HG531 V1 is connected to the Internet in router
mode, but no data is being transmitted.
WLAN
Blinking green
The HG531 V1 has WLAN enabled, and data is
being transmitted.
Steady green
The HG531 V1 has WLAN enabled, but is not
transmitting data.
WPS
Blinking green
The HG531 V1 is attempting to connect to a
wireless client over the WLAN using the WPS
function.
The WPS indicator blinks for 120 seconds or less.
Steady green
The HG531 V1 is connected to a wireless client,
such as a computer with a wireless network
adapter, over the WLAN using the Wi-Fi Protected
Setup (WPS) function.
The WPS indicator is steady on for 300 seconds.

Huawei HG531 V1 Specifications

General

Device Type	Wireless Router
Brand	Huawei
Model	HG531 V1
Wireless Standard	802.11b/g/n
Wireless Speed	Up to 150 Mbps
Frequency Band	2.4 GHz
LAN Ports	4 x 10/100Mbps
WAN Port	1 x 10/100Mbps
Security	WEP, WPA, WPA2
Antenna	1 x External
